Pedal Assist Sensors
Pedal assist sensor magnet rings with a higher number of magnets will allow the motor to produce more power when pedaling.
For example, if a magnet ring with six magnets replaces a magnet ring with five magnets, then the motor will produce more power when pedaling for faster
acceleration and stronger assistance when traveling up hills. The sensor's metal ring mounts between the frame and the bottom bracket lockring.
The magnet ring mounts to the bottom bracket spindle and should be positioned close to the sensor without touching it.
|
|
Pedal Assist Sensor with Five Magnet Ring
Standard pedal assist sensor with 5-magnet magnet ring. The sensor's
metal bottom bracket mounting ring is 35mm ID and 45mm OD. The black nylon magnet ring fits 16mm spindles. 35"
long power cable
with blue, red, and yellow wires. Small black wire connector on end of cable.
Mating connector is CNX-63 which is available on our
black wire connectors page.
Wiring Directions
Item # PAS-105
|
$5.95
 |
|
|
Pedal Assist Sensor with Six Magnet Ring
Standard pedal assist sensor with 6-magnet magnet ring. The sensor's
metal bottom bracket mounting ring is 35mm ID and 45mm OD. The black nylon magnet ring fits 16mm spindles. 35"
long power cable
with blue, red, and yellow wires. Small black wire connector on end of cable.
Mating connector is CNX-63 which is available on our
black wire connectors page.
Wiring Directions
Item # PAS-106
|
$5.95
|
|
|
Pedal Assist Sensor with Eight Magnet Ring
Standard pedal assist sensor with 8-magnet magnet ring. The sensor's
metal bottom bracket mounting ring is 35mm ID and 45mm OD. The black nylon magnet ring fits 16mm spindles. 35"
long power cable
with blue, red, and yellow wires. Small black wire connector on end of cable.
Mating connector is CNX-63 which is available on our
black wire connectors page.
Wiring Directions
Item # PAS-108
|
$5.95
|
|
